Breadboard-Plugin Components Pack is a new kit designed for breadboard experiment. It provides many kinds of components, such as resistors, capacitors, diodes, transistor .etc. The module pins are using gold-plating technology, solid and durable. It could be plugged on the breadboard directly. easy, reliable and reusable.

This innovative approach will solve the following issues caused by using DIP type of components:

Hard to read the value (Resistor color codes)
Severe deformations of the pin after used, non-reusable, not environment-friendly
The pin diameter is too thin or too thick, poor match with the breadboard hole
Confused the order of transistor “e”, “b”, “c” pins
Usage problem: Most of sensors and actuators require 3 interfaces: Signal/VCC/GND, you have to use the jumper wire for the connection, messy and unreliable.

Features

Easy to Recognize : Resistance value, capacitance values, positive/negative polaron and pin functions are marked clearly.
Easy to Learn : The circuit symbol is clearly visible, directly match the circuit diagram
Easy to Use : Direct-plug pin
Easy to Plug/unplug : The 0.64mm diametral pin matches the breadboard hole perfectly
High-Reliability : ENIG technology, the circuit connection is reliable and durable
Environment-Friendly : Reusable and Environment-friendly

Specifications

Resistor: 220R，1K，4.7K，10K
Capacitor: 22pF@50V, 100nF(0.1uF)@50V, 47uF@10V
LED: Red, Yellow, Blue, Green
Diode: If=1A, Vfm=0.7V, Vr=40V
Transistor-NPN: Vceo=45V, Ic=500mA, hFE=400
Transistor-PNP: Vceo=-45V, Ic=-500mA, hFE=400

Resources

Wiki Doc

Package Contents

4x Resistor 220R
4x Resistor 1K
4x Resistor 4.7K
4x Resistor 10K
2x Capacitor 22pF
2x Capacitor 100nF
2x Capacitor 47uF
2x LED--R
2x LED--Y
2x LED--B
2x LED--G
2x Diode
2x NPN transistor
2x PNP transistor
2x Breadboard PluginConnector
